Aluminum FR-4 Halogen Free Rogers Multiple Layer PCB FR-4 High TG
| Place of Origin | China |
|---|---|
| Brand Name | ADMG |
| Certification | ISO14001 ISO9001 |
| Model Number | OEM/ODM |
| Minimum Order Quantity | 2pcs |
| Price | Negotiation |
| Delivery Time | 5-8 working days |
| Payment Terms | L/C, D/A, D/P, T/T |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Impedance Control | Yes | Certificates | ISO9001, ISO14001, UL, RoHS |
|---|---|---|---|
| Surface Finish | HASL, ENIG, OSP, Immersion Silver, Immersion Tin | Material | FR-4, FR-4 High TG, FR-4 Halogen Free, Rogers, Aluminum |
| Solder Mask Color | Green, Blue, Black, Red, Yellow, White | Min. Line Width/Spacing | 3mil/3mil |
| High Light | rogers multiple layer pcb,aluminum multiple layer pcb |
||
Product Description
Multiple Layer PCB Introduction:
Multiple Layer PCBs, also known as multilayer printed circuit boards, are advanced electronic circuit boards that feature more than two conductive layers. These sophisticated designs offer enhanced functionality, improved signal integrity, and increased component density compared to traditional single or double-layer PCBs. The additional layers in a Multiple Layer PCB provide increased flexibility and the ability to address complex circuit requirements.
Multiple Layer PCB Specifications:
|
Parameter |
Description |
|---|---|
| Number of Layers | 4, 6, 8, or more |
| Copper Thickness | 0.5 oz to 2 oz per layer |
| Dielectric Thickness | 0.2 mm to 2 mm |
| Material | FR-4, Rogers, Polyimide, etc. |
| Minimum Trace Width | 3 mil to 10 mil |
| Minimum Drill Size | 0.3 mm to 0.8 mm |
| Impedance Control | 50 Ω, 75 Ω, or custom |
| Surface Finish | ENIG, HASL, Immersion Gold, etc. |
| Solder Mask | Liquid Photo Imageable (LPI), Dry Film |
| Legend | Silk Screen, Laser Printed |
Multiple Layer PCB Application Usage:
Multiple Layer PCBs are widely used in a variety of industries, including telecommunications, aerospace, automotive, industrial automation, and consumer electronics. These advanced circuit boards are essential for designs that require high-speed data transmission, increased component density, and complex interconnections. Their versatility makes them a crucial component in many modern electronic devices and systems.
Multiple Layer PCB Features:
- Improved signal integrity and reduced electromagnetic interference (EMI) through the shielding effect of additional layers
- Enhanced thermal management capabilities for high-power applications
- Support for advanced technologies like high-speed digital, RF, and mixed-signal circuits
- Increased design flexibility and the ability to route critical signals on dedicated layers
Multiple Layer PCB Advantages:
- Improved reliability and durability due to the robust multi-layer construction
- Cost-effective solution for high-volume production and complex circuit designs
- Compatibility with a wide range of manufacturing processes and surface finishes
- Enhanced power distribution and ground plane design for improved circuit performance
Request for Quotation (RFQ):
If you are interested in our Custom Tactile Membrane Switch, please provide the following information for a quotation:
