0.2mm-6.0mm Multiple Layer PCB For Enhanced Functionality 0.5oz-6oz
| Place of Origin | China |
|---|---|
| Brand Name | ADMG |
| Certification | ISO14001 ISO9001 |
| Model Number | OEM/ODM |
| Minimum Order Quantity | 2pcs |
| Price | Negotiation |
| Delivery Time | 5-8 working days |
| Payment Terms | L/C, D/A, D/P, T/T |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Min. Hole Copper | 20μm | Board Thickness | 0.2mm-6.0mm |
|---|---|---|---|
| Testing | Flying Probe Test, X-ray Inspection, AOI, Etc. | Copper Thickness | 0.5oz-6oz |
| Layer Count | 2-20 Layers | Smt Pitch | 0.3mm |
| High Light | 6.0mm multiple layer pcb,0.2mm multiple layer pcb |
||
Product Description
Next Generation Multiple Layer PCB For Enhanced Functionality
Multiple Layer PCB Introduction:
Multiple Layer PCBs, also referred to as multilayer printed circuit boards, are advanced electronic circuit boards that feature more than two conductive layers. These intricate designs offer enhanced capabilities, improved signal quality, and increased component density compared to traditional single or double-layer PCBs.
Multiple Layer PCB Specifications:
|
Parameter |
Description |
|---|---|
| Number of Layers | 4, 6, 8, or more |
| Copper Thickness | 0.5 oz to 2 oz per layer |
| Dielectric Thickness | 0.2 mm to 2 mm |
| Material | FR-4, Rogers, Polyimide, etc. |
| Minimum Trace Width | 3 mil to 10 mil |
| Minimum Drill Size | 0.3 mm to 0.8 mm |
| Impedance Control | 50 Ω, 75 Ω, or custom |
| Surface Finish | ENIG, HASL, Immersion Gold, etc. |
| Solder Mask | Liquid Photo Imageable (LPI), Dry Film |
| Legend | Silk Screen, Laser Printed |
Multiple Layer PCB Application Usage:
Multiple Layer PCBs are essential for a wide range of industries, including telecommunications, aerospace, automotive, and consumer electronics. These advanced circuit boards are crucial for designs that require high-speed data transmission, increased component density, and complex interconnections.
Multiple Layer PCB Features:
- Improved signal integrity and reduced electromagnetic interference (EMI) through the shielding effect of additional layers
- Enhanced thermal management capabilities for high-power applications
- Ability to route critical signals on dedicated layers for better performance
- Product Advantages:
- Increased design flexibility and the ability to address complex circuit requirements
- Improved reliability and durability due to the robust multi-layer construction
- Cost-effective solution for high-volume production and complex circuit designs
Request for Quotation (RFQ):
If you are interested in our Custom Tactile Membrane Switch, please provide the following information for a quotation:
- Customization requirements, including size, shape, graphics, layout, and backlighting
- Quantity needed
- Application and industry details
- Specific environmental considerations (e.g., waterproof or dustproof requirements)
- Delivery time and location requirements
