FR-4 Polyimide Advanced Multiple Layer PCB HASL ENIG OSP Immersion Silver
| Place of Origin | China |
|---|---|
| Brand Name | ADMG |
| Certification | ISO14001 ISO9001 |
| Model Number | OEM/ODM |
| Minimum Order Quantity | 2pcs |
| Price | Negotiation |
| Delivery Time | 5-8 working days |
| Payment Terms | L/C, D/A, D/P, T/T |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| RoHS Compliance | Yes | Surface Mount Technology (SMT) | Yes |
|---|---|---|---|
| Silkscreen | White, Black, Yellow, Etc. | Solder Mask | Green, Red, Blue, Black, White, Yellow, Etc. |
| Surface Finish | HASL, ENIG, OSP, Immersion Silver, Etc. | Material | FR-4, FR-4 High Tg, Polyimide, Rogers, Etc. |
| High Light | fr-4 multiple layer pcb,polyimide multiple layer pcb |
||
Product Description
Multiple Layer PCB Introduction:
Multiple Layer PCBs, also known as multilayer printed circuit boards, are advanced electronic circuit boards that consist of more than two conductive layers. These intricate designs offer enhanced functionality, improved signal integrity, and increased component density compared to traditional single or double-layer PCBs.
Multiple Layer PCB Specifications:
|
Parameter |
Description |
|---|---|
| Number of Layers | 4, 6, 8, or more |
| Copper Thickness | 0.5 oz to 2 oz per layer |
| Dielectric Thickness | 0.2 mm to 2 mm |
| Material | FR-4, Rogers, Polyimide, etc. |
| Minimum Trace Width | 3 mil to 10 mil |
| Minimum Drill Size | 0.3 mm to 0.8 mm |
| Impedance Control | 50 Ω, 75 Ω, or custom |
| Surface Finish | ENIG, HASL, Immersion Gold, etc. |
| Solder Mask | Liquid Photo Imageable (LPI), Dry Film |
| Legend | Silk Screen, Laser Printed |
Multiple Layer PCB Application Usage:
Multiple Layer PCBs are widely used in a variety of industries, including telecommunications, aerospace, automotive, industrial automation, and consumer electronics. These advanced circuit boards are essential for designs that require high-speed data transmission, increased component density, and complex interconnections.
Multiple Layer PCB Features:
- Improved signal integrity and reduced electromagnetic interference (EMI) due to the shielding effect of the additional layers
- Increased component density and more efficient use of board space
- Enhanced thermal management capabilities
- Ability to route critical signals on dedicated layers
- Improved power distribution and ground plane design
- Support for advanced technologies like high-speed digital, RF, and mixed-signal circuits
Product Advantages:
- Enhanced functionality and performance compared to traditional PCB designs
- Increased design flexibility and the ability to address complex circuit requirements
- Improved reliability and durability due to the robust multi-layer construction
- Cost-effective solution for high-volume production and complex circuit designs
- Compatibility with a wide range of manufacturing processes and surface finishes
Request for Quotation (RFQ):
If you are interested in our Custom Tactile Membrane Switch, please provide the following information for a quotation:
- Customization requirements, including size, shape, graphics, layout, and backlighting
- Quantity needed
- Application and industry details
- Specific environmental considerations (e.g., waterproof or dustproof requirements)
- Delivery time and location requirements
